Draw a Profile Glyph

Source: R/profileglyphGrob.R
profileglyphGrob.Rd

Uses Grid graphics to draw a profile glyph (Chambers et al. 1983; duToit et al. 1986) .

Usage

profileglyphGrob(
  x = 0.5,
  y = 0.5,
  z,
  size = 1,
  col.bar = "black",
  col.line = "black",
  fill = NA,
  lwd.bar = 1,
  lwd.line = 1,
  alpha = 1,
  width = 5,
  flip.axes = FALSE,
  bar = TRUE,
  line = TRUE,
  mirror = TRUE,
  linejoin = c("mitre", "round", "bevel"),
  lineend = c("round", "butt", "square"),
  grid.levels = NULL,
  draw.grid = FALSE,
  col.grid = "grey",
  lwd.grid = 1
)

Arguments

x

A numeric vector or unit object specifying x-locations.

y

A numeric vector or unit object specifying y-locations.

z

A numeric vector specifying the values to be plotted as dimensions of the profile (length of the bars).

size

The size of glyphs.

col.bar

The colour of bars.

col.line

The colour of profile line(s).

fill

The fill colour.

lwd.bar

The line width of the bars.

lwd.line

The line width of the profile line(s)

alpha

The alpha transparency value.

width

The width of the bars.

flip.axes

logical. If TRUE, axes are flipped.

bar

logical. If TRUE, profile bars are plotted.

line

logical. If TRUE, profile line is plotted.

mirror

logical. If TRUE, mirror profile is plotted.

linejoin

The line join style for the profile line(s) and bars. Either "mitre", "round" or "bevel".

lineend

The line end style for the whisker lines. Either "round", "butt" or "square".

grid.levels

A list of grid levels (as vectors) corresponding to the values in z at which grid lines are to be plotted. The values in z should be present in the list specified.

draw.grid

logical. If TRUE, grid lines are plotted along the bars. Default is FALSE.

col.grid

The colour of the grid lines.

lwd.grid

The line width of the grid lines.

Value

A gTree object.

References

Chambers JM, Cleveland WS, Kleiner B, Tukey PA (1983). Graphical Methods for Data Analysis. Chapman and Hall/CRC, Boca Raton. ISBN 978-1-351-07230-4.

duToit SHC, Steyn AGW, Stumpf RH (1986). Graphical Exploratory Data Analysis, Springer Texts in Statistics. Springer-Verlag, New York. ISBN 978-1-4612-9371-2.

See also

geom_profileglyph

Other grobs: dotglyphGrob(), metroglyphGrob(), pieglyphGrob(), starglyphGrob(), tileglyphGrob()

Examples

library(ggmultiglyph)
library(grid)
library(gridExtra)

#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Profile bar, line, mirror and flip.axes combination
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE, bar = FALSE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE, mirror = FALSE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, , mirror = FALSE,
                   line = TRUE, bar = FALSE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, mirror = FALSE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE, flip.axes = TRUE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE, bar = FALSE,
                   flip.axes = TRUE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, flip.axes = TRUE)

barglyph4 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE)

profileglyph4 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, , mirror = FALSE, flip.axes = TRUE,
                   line = TRUE, bar = FALSE)

barprofileglyph4 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, mirror = FALSE, flip.axes = TRUE)

grid.arrange(barglyph1, profileglyph1, barprofileglyph1,
             barglyph2, profileglyph2, barprofileglyph2,
             nrow = 2, ncol = 3)

grid.arrange(barglyph3, profileglyph3, barprofileglyph3,
             barglyph4, profileglyph4, barprofileglyph4,
             nrow = 2, ncol = 3)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust size
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = FALSE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = TRUE, bar = FALSE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE, bar = FALSE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = TRUE, bar = FALSE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = FALSE, mirror = FALSE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = TRUE,
                   bar = FALSE, mirror = FALSE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, mirror = FALSE)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE, mirror = FALSE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE,
                   bar = FALSE, mirror = FALSE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, mirror = FALSE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE, mirror = FALSE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = TRUE,
                   bar = FALSE, mirror = FALSE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, mirror = FALSE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = FALSE, flip.axes = TRUE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = TRUE, bar = FALSE,
                   flip.axes = TRUE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, flip.axes = TRUE)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE, flip.axes = TRUE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, flip.axes = TRUE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE, bar = FALSE,
                   flip.axes = TRUE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE, flip.axes = TRUE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = TRUE, bar = FALSE,
                   flip.axes = TRUE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, flip.axes = TRUE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, line = TRUE,
                   bar = FALSE, mirror = FALSE, flip.axes = TRUE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 5, mirror = FALSE, flip.axes = TRUE)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE,
                   bar = FALSE, mirror = FALSE, flip.axes = TRUE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, mirror = FALSE, flip.axes = TRUE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = TRUE,
                   bar = FALSE, mirror = FALSE, flip.axes = TRUE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, mirror = FALSE, flip.axes = TRUE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust width
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = FALSE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = TRUE, bar = FALSE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = FALSE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = TRUE, bar = FALSE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE, bar = FALSE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = FALSE, mirror = FALSE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = TRUE,
                   bar = FALSE, mirror = FALSE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, mirror = FALSE)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = FALSE, mirror = FALSE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = TRUE,
                   bar = FALSE, mirror = FALSE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, mirror = FALSE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE, mirror = FALSE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE,
                   bar = FALSE, mirror = FALSE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, mirror = FALSE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = FALSE, flip.axes = TRUE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = TRUE, bar = FALSE,
                   flip.axes = TRUE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, flip.axes = TRUE)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = FALSE, flip.axes = TRUE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, flip.axes = TRUE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = TRUE, bar = FALSE,
                   flip.axes = TRUE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE, flip.axes = TRUE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE, bar = FALSE,
                   flip.axes = TRUE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, flip.axes = TRUE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, line = TRUE,
                   bar = FALSE, mirror = FALSE, flip.axes = TRUE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 1, mirror = FALSE, flip.axes = TRUE)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, line = TRUE,
                   bar = FALSE, mirror = FALSE, flip.axes = TRUE)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, width = 3, mirror = FALSE, flip.axes = TRUE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE,
                   bar = FALSE, mirror = FALSE, flip.axes = TRUE)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, mirror = FALSE, flip.axes = TRUE)

grid.arrange(barglyph1, barglyph2, barglyph3, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, profileglyph3, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3, nrow = 1)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust bar and profile line width
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE)

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE, bar = FALSE)

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE,
                   lwd.bar= 3)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE, bar = FALSE,
                   lwd.line = 3)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, lwd.bar= 3, lwd.line = 3)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = FALSE,
                   lwd.bar= 5)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, line = TRUE, bar = FALSE,
                   lwd.line = 5)

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 10, lwd.bar= 5, lwd.line = 5)

grid.arrange(barglyph1, barglyph2, barglyph3,
             profileglyph1, profileglyph2, profileglyph3,
             barprofileglyph1, barprofileglyph2, barprofileglyph3,
             nrow = 3, ncol = 3)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust bar and line colour
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE,
                   col.bar = "cyan")

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE, bar = FALSE,
                   col.line = "green")

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15,
                   col.bar = "salmon", col.line = "salmon")

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE,
                   fill = "cyan")

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE, bar = FALSE,
                   fill = "green")

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15,
                   fill = "salmon")

grid.arrange(barglyph1, barglyph2, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, nrow = 1)


barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE,
                   mirror = FALSE, col.bar = "cyan")

profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE, bar = FALSE,
                   mirror = FALSE, col.line = "green")

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15,
                   mirror = FALSE, col.bar = "salmon", col.line = "salmon")

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = FALSE,
                   mirror = FALSE, fill = "cyan")

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15, line = TRUE, bar = FALSE,
                   mirror = FALSE, fill = "green")

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 15,
                   mirror = FALSE, fill = "salmon")

grid.arrange(barglyph1, barglyph2, nrow = 1)

grid.arrange(profileglyph1, profileglyph2, nrow = 1)

grid.arrange(barprofileglyph1, barprofileglyph2, nrow = 1)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Multivariate bar fill colour
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE, mirror = FALSE,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, mirror = FALSE,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE, flip.axes = TRUE,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, flip.axes = TRUE,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barglyph4 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, line = FALSE,
                   mirror = FALSE, flip.axes = TRUE,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barprofileglyph4 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 20, mirror = FALSE, flip.axes = TRUE,
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

grid.arrange(barglyph1, barprofileglyph1,
             barglyph2, barprofileglyph2,
             nrow = 2, ncol = 2)

grid.arrange(barglyph3, barprofileglyph3,
             barglyph4, barprofileglyph4,
             nrow = 2, ncol = 2)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust line join style
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.bar = 10, width = 5,
                   line = FALSE)

barglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.bar = 10, width = 5,
                   linejoin = "round", line = FALSE)

barglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.bar = 10, width = 5,
                   linejoin = "bevel", line = FALSE)

grid.arrange(barglyph1, barglyph2, barglyph3,
             nrow = 1, ncol = 3)


profileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.line = 10, width = 5,
                   bar = FALSE)

profileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.line = 10, width = 5,
                   linejoin = "round", bar = FALSE)

profileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.line = 10, width = 5,
                   linejoin = "bevel", bar = FALSE)

grid.arrange(profileglyph1, profileglyph2, profileglyph3,
             nrow = 1, ncol = 3)


barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.bar = 10, width = 5)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.bar = 10, width = 5,
                   linejoin = "round")

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.bar = 10, width = 5,
                   linejoin = "bevel")

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3,
             nrow = 1, ncol = 3)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust line end style
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.line = 10, width = 5)

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.line = 10, width = 5,
                   lineend = "butt")

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(0.24, 0.3, 0.8, 1.4, 0.6, 0.33),
                   size = 25, lwd.line = 10, width = 5,
                   lineend = "square")

grid.arrange(barprofileglyph1, barprofileglyph2, barprofileglyph3,
             nrow = 1, ncol = 3)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust grid levels
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

# Grid lines
gl <- split(x = rep(c(1, 2, 3), 6),
            f = rep(1:6, each = 3))

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5,
                   draw.grid = TRUE, lwd.bar = 5,
                   grid.levels = gl, col.grid = "black")

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5, lwd.bar = 5,
                   draw.grid = TRUE, mirror = FALSE,
                   grid.levels = gl, col.grid = "black")

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5, flip.axes = TRUE,
                   draw.grid = TRUE, lwd.bar = 5,
                   grid.levels = gl, col.grid = "black")

barprofileglyph4 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5, flip.axes = TRUE,
                   draw.grid = TRUE, lwd.bar = 5, mirror = FALSE,
                   grid.levels = gl, col.grid = "black")

grid.arrange(barprofileglyph1, barprofileglyph2, nrow = 1)

grid.arrange(barprofileglyph3, barprofileglyph4, nrow = 1)


#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# Adjust grid level colours
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

# Grid lines
gl <- split(x = rep(c(1, 2, 3), 6),
            f = rep(1:6, each = 3))

barprofileglyph1 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5,
                   draw.grid = TRUE, lwd.bar = 5,
                   grid.levels = gl, line = FALSE,
                   col.grid = "white", col.bar = "white",
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barprofileglyph2 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5, lwd.bar = 5,
                   draw.grid = TRUE, mirror = FALSE,
                   grid.levels = gl, line = FALSE,
                   col.grid = "white", col.bar = "white",
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barprofileglyph3 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5, flip.axes = TRUE,
                   draw.grid = TRUE, lwd.bar = 5,
                   grid.levels = gl, line = FALSE,
                   col.grid = "white", col.bar = "white",
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

barprofileglyph4 <-
  profileglyphGrob(x = unit(0.5, "npc"), y = unit(0.5, "npc"),
                   z = c(1, 3, 2, 1, 2, 3),
                   size = 10, width = 5, flip.axes = TRUE,
                   draw.grid = TRUE, lwd.bar = 5, mirror = FALSE,
                   grid.levels = gl, line = FALSE,
                   col.grid = "white", col.bar = "white",
                   fill = RColorBrewer::brewer.pal(6, "Dark2"))

grid.arrange(barprofileglyph1, barprofileglyph2, nrow = 1)

grid.arrange(barprofileglyph3, barprofileglyph4, nrow = 1)
